Resistive touch technology: a timeless touch solution

    In today's market dominated by capacitive touch screens, resistive touch technology still maintains unique competitive advantages and a wide range of application scenarios. As one of the earliest commercialized touch technologies, resistive touch screens have an irreplaceable position in industrial control, medical equipment, outdoor terminals and other fields due to their reliability, low cost and compatibility with various input methods. This article will comprehensively analyze the working principle, type characteristics, application scenarios and future development of resistive touch technology.

The basic principle of resistive touch

The core of resistive touch technology lies in the pressure sensing mechanism:

• The screen consists of two layers of flexible conductive film (usually ITO) separated by a tiny spacer
• When pressure is applied, the two conductive layers touch at the touch point
• The controller measures the voltage change at the contact point and calculates the precise coordinate position
• The system transmits the coordinate information to the host for processing

This working principle based on physical contact makes the resistive screen compatible with any input tool (fingers, stylus, gloves, etc.), instead of relying on the properties of conductors like the capacitive screen.

There are two main types of resistive touch

1.4-Wire Resistive

Structural features:

• Upper film: uniform resistance layer in the X-axis direction

• Lower film: uniform resistance layer in the Y-axis direction

• Four wires lead out from the four corners for voltage measurement

Working principle:

• First, apply a voltage gradient on both sides of the upper film, and measure the voltage value output by the lower film to determine the X coordinate

• Switch to apply a voltage gradient on both sides of the lower film, and measure the voltage value output by the upper film to determine the Y coordinate

Advantages:

• Simple structure, lowest cost

• Suitable for small screens

Limitations:

• The upper film is easily worn and affects the accuracy

• Does not support multi-touch

2.5-Wire Resistive

Structural improvements:

• The lower film is responsible for both X and Y axis measurement

• The upper film is only used as a movable voltage probe

• Four wires connect the four corners of the lower film, and one wire connects the upper film

Technical advantages:

• The upper film does not pass current, which greatly extends the service life

• Higher positioning accuracy

• Stronger anti-interference ability

• Becoming the mainstream technology of current resistive screens

Technical characteristics of resistive touch

Core advantages

• Flexible input method: responds to the pressure of any object, including operation with gloves and using ordinary stylus

• Strong environmental adaptability: not affected by water, oil, dust and other environments, suitable for industrial environments

• High cost-effectiveness: simple manufacturing process, large size cost advantage

• Reliable accuracy: typical accuracy can reach ±1%, meeting the needs of precision operation

• Low power consumption: no need for continuous power supply during operation, suitable for battery devices

Main limitations

• Low transmittance: The multi-layer structure results in a transmittance of about 75-85%, which affects the display effect

• Soft surface: easily scratched by sharp objects

• Limited multi-touch: Traditional resistive screens do not support true multi-touch

• Requires a certain amount of pressure: Not as sensitive as capacitive screens when lightly touched

Typical application scenarios

• Industrial control systems: factory automation equipment, PLC control panels

• Medical equipment: operating room equipment, diagnostic instrument touch interface

• Outdoor terminals: ATM machines, ticket machines, information query terminals

• Catering and retail: POS systems, self-service ordering terminals

• Special equipment: military equipment, operating interfaces in explosion-proof environments

• Low-cost equipment: e-book readers, early PDA devices

Technological evolution and innovation

Despite being a relatively mature technology, resistive touch continues to evolve:

1.Matrix resistor technology:

• Use fine resistor grid division

• Achieve multi-touch function

• Improve anti-interference ability

2.Hybrid touch screen:

• Resistive + capacitive dual-mode design

• Taking into account both environmental adaptability and operating experience

• Such as Gunze's "Dual Touch" technology

3.Material innovation:

• More durable transparent conductive materials

• Higher light transmittance film combinations

• Thinner laminate structures

4.Digital resistance technology:

• Use digital measurement method

• Improve response speed and accuracy

• Reduce power consumption

Comparison with capacitive touch

Feature	Resistive Touch	Capacitive Touch
Input Method	Any object	Conductive objects (usually fingers)
Touch Pressure	Requires some pressure	Responds to light touches
Multi-Touch	Limited support	Native support
Environmental Resistance	Strong (water/dust resistant)	Weak (affected by water)
Light Transmittance	75-85%	Over 90%
Cost	Low (especially large sizes)	Higher
Durability	Surface scratches easily	Hard surface
Accuracy	±1%	±0.5%
Best For	Industrial/outdoor/specialized use	Consumer electronics/daily use

Future Trends

1.Deepening Industrial Applications:

• Greater role in Industry 4.0.
• Adaptation to harsher environments.

2.Hybrid Technology Development:

• Integration with capacitive tech.
• More adaptive solutions.

3.New Material Applications:

• Graphene and other transparent conductive materials.
• More durable and sensitive sensors.

4.Smart Upgrades:

• Integrated pressure sensing.
• AI-enhanced interaction.

Conclusion

    After over 30 years of development, resistive touch technology remains vital. While capacitive touch dominates consumer markets, resistive screens maintain an irreplaceable position in specialized fields due to their unique strengths. With ongoing advancements in materials and technology, resistive touchscreens will continue evolving, providing reliable solutions for industrial, specialized, and cost-sensitive applications.
